Size:  From 2.5” to 6”

Pressure Range:  From 30inHg to 1000bar

Socket:  316 St St material

Thread:  BSP, NPT, BSPT, PT, ZG, and other special specification

Bourdon Tube:  316 Stainless Steel material

   Higher Case :  304 St St ,316 St St material,polished or not polished

               Bezel:  304 St St bayonet ring or 316 St St bayonet ring

           Window:  PC lens ，glass lens or safety glass

Dial Plate:  Single ,dual or three scales(Bar,Psi,Kg/cm2,Kpa,Mpa)

Accuracy:  3-2-3%,2.5%,1.6%,1%

          Movement:  304 Stainless Steel material

               Pointer:  Aluminium or stainless Steel material（adjust type）

           Restrictor:  304 St St material

Diaphragm Seal:  316 St St material

Over Pressure:  130%

Connection Type:  One connection welded to the case
